Adjustable Lux Threshold Miniature Improved Electronic Direct Wire In Photocontrol Micro Advanced Version

Brand Name : LongJoin

Model Number : JL-412C(R)

Place of Origin : China

Price : negotiable

Packaging Details : Different packaging methods are adopted according to different modes of transport.

Payment Terms : Western Union,MoneyGram,T/T

Rated Voltage : 120~277VAC

Available Voltage Range : 105~305VAC

Power Consumption : 1W Max.

On-off Levels : 10~30Lx Turn-On / 30~80Lx Turn-Off

Certifications : RoHS,CE,UL

Real-world Scenarios : Residential Street Lighting

Contact Now

Adjustable Lux Threshold Miniature Improved Electronic Direct Wire In Photocontrol Micro Advanced Version
JL-412C Miniature Improved Electronic Direct Wire-In Photocontrol, Micro Advanced Version

The photocontrol JL-412C(R) is applicable to control the passage lighting and doorway lighting automatically in accordance with the ambient lighting level.

This product is designed with electronic circuits. Its quicker response with time delay of 3-10 seconds offers easy-to-test feature, while a miniature profile supports most smaller fixtures. Further, a preset 3-10 seconds time-delay might avoid redundancy operation due to spotlight or lightning during the night time.

This product has been listed by UL LLC and is comply with the Standard for Non-industrial Photoelectric Switches for Lighting Control UL773A. Its R version provides a separated sensor assembly.

Product Size
Adjustable Lux Threshold Miniature Improved Electronic Direct Wire In Photocontrol Micro Advanced Version
Product Features
  • UL773A direct wire-in
  • 120~277V Multi-Volts
  • IR-Filtered Phototransistor Sensor
  • IP65 protection
  • Miniature size
Specifications
Model No. JL-412C JL-412CR
Rated Voltage 120~277VAC
Available Voltage Range 105~305VAC
Rated Frequency 50/60Hz
Rated Loading 1.2A Tungsten / Ballast 1A e-Ballast
Power Consumption 1W Max.
On-off Levels 10~30Lx Turn-On / 30~80Lx Turn-Off
Ambient Temperature -40℃ ~ +70℃
Related Humidity 96%
Leads Length AWG #18, AWM1430
Certifications Adjustable Lux Threshold Miniature Improved Electronic Direct Wire In Photocontrol Micro Advanced Version
Frequently Asked Questions
What is an adjustable lux threshold miniature advanced photocontrol?

It is a compact, high-performance light sensor designed for direct wire installation. It features an adjustable light level threshold for precise on/off control, making it an improved, advanced version of standard miniature photocontrols.

What does adjustable lux threshold mean in this photocontrol?

Adjustable lux threshold allows users to set the exact light level at which the photocontrol automatically turns lights on or off. This provides greater flexibility than fixed-sensitivity models for different lighting applications.

Is this advanced miniature photocontrol designed for direct wire installation?

Yes. It features a direct wire design for simple, secure hardwiring into lighting systems, without extra adapters. Its miniature size allows installation in tight spaces.

What makes this an improved and advanced version of photocontrols?

It offers enhanced stability, more precise lux adjustment, better energy efficiency, and a more compact form factor compared to standard miniature photocontrols, delivering more reliable dusk-to-dawn operation.

What lighting applications is this micro advanced photocontrol suitable for?

It is ideal for streetlights, wall packs, floodlights, landscape lights, and other small fixtures where a miniature size, direct wiring, and adjustable light sensitivity are required.
